  • 16-channel mixer featuring signature high-headroom, low-noise design
  • 16 boutique-quality Onyx mic preamps
  • Improved RF rejection ideal for broadcast applications
  • Integrated phantom power
  • 4 AUX sends, level, pan & solo & overload/mute LEDs on each channel
Warranty:  1 Year
Mackie
  • Unrivalled Advice

    Our experts are ready to help. See our feedback:

    Trust Pilot
  • Free Delivery

    Free UK saver delivery on all our products.
    More info

  • No Fuss Returns

    Refund or exchange within 30 days. More info

Secured by Thawte

Mackie Studio Mixer

Mackie 1604-VLZ4 Studio Mixer ups the level of sonic quality at every level, featuring Mackie's flagship Onyx mic preamps and premium components from front to back. The result is the most rock solid, the most easy to use and, yes, the best sounding compact mixer ever created.

Now featuring Mackie's flagship Onyx mic preamps, the comprehensive Mackie VLZ4 line delivers the proven feature set, high-headroom/low-noise design and "Built-Like-A-Tank" construction that created an industry more than 25 years ago. From every input to every output, VLZ4 is optimized to deliver professional-quality results each and every time.

There are 16 onboard, studio-grade Onyx mic preamps that are designed for low-input applications. The preamps offer an ultra-wide 60 dB gain range and 128.5 dB dynamic range. With an extended frequency response, the preamps also offer incredibly low distortion levels.

  • 16-channel mixer featuring signature high-headroom, low-noise design
  • 16 boutique-quality Onyx mic preamps
  • Ultra-wide 60 dB gain range
  • 128.5 dB dynamic range
  • +22 dBu line input handling
  • Extended frequency response
  • Improved RF rejection ideal for broadcast applications
  • Integrated phantom power
  • 16 high-headroom line inputs with +4/-10 operation control
  • 3-band EQ (80Hz, 2.5kHz, 12kHz)
  • 18 dB/ oct 75Hz low-cut filter on mic input channels
  • 4 AUX sends, level, pan & solo & overload/mute LEDs on each channel
  • 60mm long-wearing log-taper faders
  • 4 stereo returns, 8 direct outs & 4 group/bus outputs
  • Control room/phones source matrix
  • High-resolution 12-segment stereo metres
  • Sealed rotary controls resist dust & grime
  • Rugged steel chassis with powder-coat finish
  • High-visibility, high-contrast controls
Main Mix Noise

Main Mix Fader Unity, Channel Faders Down: -88.5 dBu
Main Mix Fader @ Unity, Channel Faders @ Unity: -82.5 dBu

Total Harmonic Distortion (20Hz - 20kHz THD)

Mic In To Insert Send: %lt;0.0007 Percent
Mic In To Main Out: <0.005 Percent

Attenuation/Crosstalk

Channel Mute Switch Engaged: -84 dBu
Channel Gain Knob Down: -84 dBu

Frequency Response

Mic Input to Main Output: +0, -1 dB, 20Hz to 50kHz. +0, -3 dB, <10Hz to >100kHz

Equivalent Input Noise

150Ω Termination: -128.5 dBu, 20Hz - 20kHz

Common Mode Rejection Ratio

1kHz: Better Than -70 dB

Maximum Levels

Mic In: +22 dBu
All Other Inputs: +22 dBu
Main Mix TRS Out: +28 dBu
All Other Outputs: +22 dBu

Impedance

Mic In: 2.5kΩ
Channel Insert Return: 2.5kΩ
All Other Inputs: 10kΩ Or Greater
Tape Out: 1.1kΩ
All Other Outputs: 120Ω

EQ

High Shelving: ±15 dB @ 12kHz
Mid Peaking: ±15 dB Sweep 100Hz - 8kHz
Low Shelving: ±15 dB @ 80Hz
Low Cut Filter: 18 dB/Octave, -3 dB @ 75Hz

AC Power Requirements

Power Consumption: 50W
UK: 200-240 VAC, 50/60Hz
Operating Temperature: 0° - 40°C

Weight

9.1kg

Dimensions (W x D x H)

440 x 433 x 129mm
